Acousto-optic modulators (AOMs) operating at 780nm have become indispensable in laser-based experiments, particularly in quantum optics and atomic physics. Fiber coupling simplifies system integration, but selecting the right fiber—single-mode (SM) versus polarization-maintaining (PM)—is crucial for achieving optimal performance.

Understanding the Fiber Options

Single-mode fibers allow light to propagate in a single transverse mode, ensuring low-loss transmission and excellent spatial beam quality. They are widely used for general applications where polarization stability is not critical. Polarization-maintaining fibers, on the other hand, are designed to preserve the input polarization along a defined axis. PM fibers are essential when precise polarization control is required, such as in optical pumping, interferometry, or Raman transitions.

Integration Considerations

Alignment Sensitivity

Coupling into SM fibers requires precise alignment of the optical mode to the fiber core. Misalignment can lead to reduced coupling efficiency and power fluctuations. PM fibers are even more sensitive because the input polarization must match the fiber's slow or fast axis. Incorrect alignment can result in polarization drift and reduced diffraction efficiency when used with polarization-sensitive optics.

Polarization Stability

780nm fiber AOMs often require well-defined polarization to maximize diffraction efficiency. While SM fibers can transmit light efficiently, they do not preserve polarization, making them unsuitable for experiments requiring high polarization fidelity. PM fibers maintain polarization over long distances and under mechanical stress, providing stable output crucial for consistent AOM performance.

Thermal and Mechanical Sensitivity

Both fiber types are affected by temperature and mechanical strain, but PM fibers are more sensitive to bending or twisting. Careful routing and strain relief are necessary to prevent polarization rotation, which can compromise AOM efficiency. SM fibers are less demanding in this respect, offering easier handling but at the cost of polarization control.

Power Handling

Fiber-coupled 780nm AOMs can operate at varying optical powers. Both SM and PM fibers can handle moderate powers, but PM fibers require more careful consideration of mode field alignment to prevent localized heating and polarization degradation.

Practical Guidelines for Integration

For experiments where polarization control is critical, always use PM fiber. Ensure proper alignment to the fiber axis and minimize mechanical stress along the fiber length.

For applications prioritizing simplicity and high coupling efficiency without strict polarization requirements, SM fiber is sufficient.

When switching between fibers or integrating into existing setups, test diffraction efficiency and polarization to verify optimal performance.

Employ fiber connectors or fusion splicing with care to maintain low insertion loss and preserve polarization in PM systems.

Conclusion

Integrating 780nm fiber AOMs requires careful consideration of the fiber type. Single-mode fibers offer ease of use and high spatial quality but do not preserve polarization, while polarization-maintaining fibers provide stable polarization essential for high-precision optical experiments. By understanding the strengths and limitations of each fiber type and following best practices for alignment and handling, researchers can optimize AOM performance and ensure reliable operation in their optical systems.
